台湾JGH久冈J-RPCC插装阀
SYMBOL J-RPCC-※ J-RPEC-※ J-RPGC-※ J-RPIC-※ |
SPECIFICATION
MODLE | MAX.OPERATING PRESSURE kgf/cm2 |
PRESSURE TYPE | PRESSURE ADJ.RANG kgf/cm2 |
MAX. FLOW l/min |
WEIGHT kg |
---|---|---|---|---|---|
J-RPCC-※ | 350 | A B C Q W |
A:5-120
B:5-105 C:10.5-420 D:5-55 W:10.5-315 |
45 | 0.17 |
J-RPEC-※ | 95 | 0.3 | |||
J-RPGC-※ | 200 | 0.64 | |||
J-RPIC-※ | 380 | 1.31 |
HOW TO ORDER
J | - | RPCC | - | A | - | L | ||
---|---|---|---|---|---|---|---|---|
KNOB TYPE L:INNER HEXANGULAR BOLT ROD ADJUST K:HAFT TURNING KNOB BOLT ROD ADJUST. |
||||||||
A:5-210 kgf/cm2 B:5-105 kgf/cm2 C:10.5-420 kgf/cm2 Q:15-55 kgf/cm2 W:10.5-315 kgf/cm2 |
||||||||
VALVE SIZE RPCC:45 l/min RPEC:95 l/min RPGC:200 l/min RPIC:380 l/min |
||||||||
SERIES NUMBER |
